OTA Remote Tuya Smart Control Panel Screen BLE Mesh Gateway For Smart Hotels

Brand Name:	SIXWGH
Model Number:	WHZK-003
MOQ:	500
Price:	USD+55-65piece
Payment Terms:	L/C,D/A,D/P,T/T,Western Union
Supply Ability:	10000+piecex+10days

Detail Information

Product Description

Detail Information

Place of Origin:

Shenzhen, China

Certification:

CE,RoHS,FCC,UL

Cost Efficiency:

Eliminates Need For Separate Gateways And Switches.

Sub-device Capacity:

Manages 128 Sub-devices Via BLE Mesh.

OEM Services:

Custom Logo, UI Language, Packaging.

Scene Control:

One-touch "Away/Home" Modes For Energy Saving.

Partition Control:

Ideal For Hotel Room Isolation Management.

Wiring Standard:

Compatible With EU/UK/CN 86mm Boxes.

Certification:

CE, RoHS, FCC Approved.

Firmware:

OTA Remote Upgrade Support.

Voltage:

Wide Range 100V-240V For Global Export.

Application:

Smart Hotels, Luxury Apartments, Office Renovation.

Packaging Details:

36*25*20cm/12pcs/3.8kg

Highlight:

OTA tuya smart control panel

BLE tuya smart control panel

OTA tuya smart screen panel

Product Description

Wholesale Tuya Smart Control Panel Mini BLE Mesh Gateway IR Controller

Engineered for modern smart buildings, the PP06 panel integrates a BLE Mesh Gateway and IR controller into a standard switch form factor. This advanced control solution replaces traditional 3-gang switches while offering unified control for lighting, HVAC, and security systems.

Core Technical Specifications

Parameter	Specification
Platform	Tuya Smart / Smart Life (GDPR Compliant)
Gateway Capacity	Supports up to 128 BLE Mesh Sub-devices
Relay Output	3 Channels (Lighting/Fan Control)
Wiring	Live + Neutral + 3 Load Lines
Material	V0 Fire-retardant PC + Tempered Glass
Integration	Supports Zigbee/BLE devices via Tuya Eco
IR Library	12 Categories of IR Appliances
System	Linux-based OS (Fast boot)

Product Features

Seamless integration of BLE Mesh Gateway and IR controller in standard switch form factor
Replaces traditional 3-gang switches with smart functionality
Unified control for lighting, HVAC, and security systems
Partition control capabilities for hotel management applications
Full OEM API/SDK integration available for custom solutions
Proximity sensor with customizable screen saver settings

Product Images

Frequently Asked Questions

Does this panel support Zigbee devices?

This specific model (PP06 Mini) is primarily a Wi-Fi + BLE Mesh Gateway. It connects Bluetooth Mesh devices directly. To control Zigbee devices, they must be on the same Tuya account (via a separate Zigbee hub), or you can request our Zigbee-integrated version for bulk orders.

Can we customize the UI language for our local market?

Yes. The system currently supports 19 languages and we are continuously adding more. For large OEM orders, we can flash specific default languages or boot logos to match your brand identity.

What is the max load for the physical switches?

The device features 3 relay channels. The maximum load is 200W per gang. It is designed for lighting control (LED, Incandescent) and is not recommended for heavy-duty appliances like heaters or pumps without an external contactor.

How does the "Partition Control" work for hotels?

This feature allows device isolation. In a hotel setting, you can configure the panel to only control devices within that specific room (Single Room Control) or allow Master Control for suites (Multiple Rooms), ensuring guests don't accidentally control neighboring rooms.

Is the screen always on?

No, it has a built-in proximity sensor and screen saver settings. You can set it to display a digital clock, weather, or turn off completely when not in use to extend screen life and save energy.

Manufacturing Capabilities: Full OEM support available with API/SDK integration for custom solutions. Bulk order customization including language localization, branding, and specialized firmware configurations.
